Available in two different sizes: 120 and 252 liters
Temperature range: -10°C to 60°CPowerful and reliable N-Smart™ microprocessor control system.Massive data storage with internal memory that can stores the records up to ten years with one hour intervals as digitally and graphically.20 program memories with 20 steps
| Model | ES 120 | ES 252 |
|---|---|---|
| Chamber Volume (liters) | 120 | 252 |
| Control System | N-Smart™ | N-Smart™ |
| Control System | With Programmable Microprocessor | With Programmable Microprocessor |
| Display | 43’’ Colourful TFT LCD | 43’’ Colourful TFT LCD |
| Display | – | – |
| Temperature Range | -10°C to +60°C | -10°C to +60°C |
| Temperature Setting and Reading Sensitivity | 0.1°C | 0.1°C |
| Temperature Homogeneity | (@ 4°C, 22°C and 37°C)±0.5°C | (@ 4°C, 22°C and 37°C)±0.5°C |
| Programmable Alarm Limits | ±1°C at 10°C Audible and Visual | ±1°C at 10°C Audible and Visual |
| Number of Program Memory | 2 | 0 |
| Programmable Number of Steps | 2 | 0 |
| Number of Program Repetition | 1 - 99 | 1 - 99 |
| Timer | 1 min – 100 Hours + Hold Position | 1 min – 100 Hours + Hold Position |
| Delayed Start Timer | 1 min – 100 Hours | 1 min – 100 Hours |
| Alarm | Audible and visual | Audible and visual |
| Insulation | High density injected polyurethane | High density injected polyurethane |
| Internal Material | Stainless steel | Stainless steel |
| External Material | Electrostatic powder coated stainless steel sheet | Electrostatic powder coated stainless steel sheet |
| Number of shelves (standard/max) PCS | 2/103/20 | 2/103/20 |
| Power Supply | 230 V - 50 Hz | 230 V - 50 Hz |
| Power Consumption | 800 W1250 W | 800 W1250 W |
| Internal Dimensions (WxDxH) mm | 480x545x600475 x 545 x 1110 | 480x545x600475 x 545 x 1110 |
| External Dimensions (WxDxH) mm | 655x745x1020650x745x1855 | 655x745x1020650x745x1855 |
| Packing Dimensions (WxDxH) mm | 770x890x1190700x860x2040 | 770x890x1190700x860x2040 |
| Net/Packed Weight kg | 89 / 117150 / 175AccessoriesCat Nos.DescriptionQty/PackFACTORY FITTED OPTIONES XXX WFWi-Fi connectioneachOPTIONSA 08 190NuveCom™ communication Unit USB port to store the temperature records on memory stick World-wide access via ethernet port with NuveCloser™ Rapid support by sending e-mails with the details of the failure RS 232 port for PC or AlerText™eachA 08 191AlerText™ GSM | 89 / 117150 / 175AccessoriesCat Nos.DescriptionQty/PackFACTORY FITTED OPTIONES XXX WFWi-Fi connectioneachOPTIONSA 08 190NuveCom™ communication Unit USB port to store the temperature records on memory stick World-wide access via ethernet port with NuveCloser™ Rapid support by sending e-mails with the details of the failure RS 232 port for PC or AlerText™eachA 08 191AlerText™ GSM |
| alarm | module (should be ordered with A 08 190)eachA 08 195NuveCloser™ Software for PC with 3 m. RS 232 cable (should be ordered with A 08 190)eachA 08 231NuveCloser™ Multi Software (connection up to 15 devices)eachACCESSORIESR 01 130Shelf for ES 120/252eachK 23 040Shelf carrier for ES 120/252each | module (should be ordered with A 08 190)eachA 08 195NuveCloser™ Software for PC with 3 m. RS 232 cable (should be ordered with A 08 190)eachA 08 231NuveCloser™ Multi Software (connection up to 15 devices)eachACCESSORIESR 01 130Shelf for ES 120/252eachK 23 040Shelf carrier for ES 120/252each |
