REMI Stability Chambers are designed as per ICH Guidelines for precise monitoring of temperature and humidity conditions required for long term, intermediate & accelerated stability studies at chemical, pharmaceutical, agrochemical manufacturing facilities. These chambers are manufactured to comply with GMP requirements.Fulfills storage conditions of 25°C – 60% RH, 40°C – 75% M RH, 30°C – 65% RHPrecise monitoring of temperature and humidity conditions
Unique design of thermal barrier for better energy efficiency
Machine filled CFC free PUF insulation to eliminate void pockets
Powerful fan motor for forced air circulation to maintain uniform conditions inside chamber within permissible limit Heating by long life SS tubular heaters
Hermetically sealed Compressor with CFC free refrigerant
Chamber calibration port on side
Adjustable trays
Output for remote alarm
Microprocessor controller with LCD display & capacitance type sensor4 ” attractive LCD display for direct display of humidity & temperature
Auto tuning of controller
Battery Backup for Controller
Settable High / Low alarm points
Centronic interface to record temperature, Humidity, Date & Time by attaching Dot Matrix printer with adjustable print interval
REMI “Datasoft” data acquisition software complying to 21 CFR part 11 as per USFDA Guidelines (Optional)Power failure and resumption recorded with date and time
PC communication through RS – 485 with data acquisition software
High temperature safety cut off & alarms for high/low set parameters
Low water level alarm and power cutoff of boiler tank heater
Time delay for compressor switch on
Overload cut off relay for compressor
Rounded inner chamber for easy cleaning
Auto door closer
Attractive door profile
Data logger for 8 point (4+4) temperature / humidity recording with sensor, printer interface and software (Optional)Weight carrying capacity of each tray : 30 Kg Uniformly distributed
Smart Handle with LED door Closure indication
Optional
Touch screen display ( TFT ) with additional features(Details overleaf)Validation protocol with IQ, OQ, PQ Documentation
Port for calibration probes / safety back up
| Model | SC-6 Plus | SC-10 Plus | SC-12 Plus | SC-16 Plus | SC-19 Plus | SC-28 Plus | SC-35 Plus |
|---|---|---|---|---|---|---|---|
| W x D x H | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions | (mm)660 x 655 x 450660 x 655 x 650660 x 655 x 850660 x 655 x 1050660 x 655 x 1250800 x 800 x 1250800 x 800 x 1580External Dimensions |
| W x D x H | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 | (mm)800 x 1095 x 1020800 x 1095 x 1220800 x 1095 x 1420800 x 1095 x 1620800 x 1095 x 1820960 x 1370 x 1950960 x 1370 x 2270 |
| Temperature Range | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor | & Accuracy10°C to 60°C, ± 1°CHumidity Range (Rh) & Accuracy40% to 95%, ± 3%Temperature & Humidity controlMicroprocessor with Capacitance type sensor |
| Display | 4? LCD Screen, Large size | 4? LCD Screen, Large size | 4? LCD Screen, Large size | 4? LCD Screen, Large size | 4? LCD Screen, Large size | 4? LCD Screen, Large size | 4? LCD Screen, Large size |
| Display | for ease of readingPower Failure | for ease of readingPower Failure | for ease of readingPower Failure | for ease of readingPower Failure | for ease of readingPower Failure | for ease of readingPower Failure | for ease of readingPower Failure |
| Alarm | Visual | Visual | Visual | Visual | Visual | Visual | Visual |
| Alarm | Door Open | Door Open | Door Open | Door Open | Door Open | Door Open | Door Open |
| Alarm | Audio Visual | Audio Visual | Audio Visual | Audio Visual | Audio Visual | Audio Visual | Audio Visual |
| Alarm | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation | in case door open for over one minuteHumidity/Temperature Variation |
| Alarm | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual | Set Humidity ± 3% Rh, Set Temperature ± 1°C, Audio Visual |
| Alarm | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade | Illumination8 Watts Fluorescent TubeInternal Body MaterialStainless Steel – 316 gradeExternal Body MateriaStainless Steel – 304 grade |
| Insulation | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam | 80 mm minimum for Body & 80 mm for Door, CFC free polyurethane foam |
| Noise | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) | LevelLess Than 65 db(A) |
| Recommended Voltage Stabilizer | VS-04VS-07VS-07 | VS-04VS-07VS-07 | VS-04VS-07VS-07 | VS-04VS-07VS-07 | VS-04VS-07VS-07 | VS-04VS-07VS-07 | VS-04VS-07VS-07 |
| Supply | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. | 220-240 Volts, 50 Hz Single Phase. |
